| Features Of Front Shovel Excavators
| Main Parameters
| Length*width*height | 9600*2990*3000mm |
|
Rated Power |
128.5KW |
| Machine weight | 22300KG |
| Main Parts of Hydraulic Excavator
We provide more optional parts to complete more kinds of work. We provide a variety of work tools such as grabs, forks, pulverizers, etc. to meet your various application needs. In addition, a variety of fixtures are provided to optimize the performance of the machine. The auxiliary hydraulic lines are arranged on the base of the boom, making the auxiliary hydraulic circuit easier to install, thereby reducing the time, parts and costs required for installing work tools.
| Why Choose Us
At Quanzhou Jingli Engineering And Machinery Co., Ltd., we are constantly seeking to improve and enhance our product offerings. We stay up-to-date with the latest trends and technology in the industry, enabling us to develop excavators that are both innovative and efficient. We are always seeking new and better ways to serve our customers and exceed their expectations.
| Company
| Workshop Display
| Process
| Exhibition Show
| Certificates
FAQ
Q:What is the best price you can offer?
A:We will check the best price after know more details.
Q: How to know the price?
A: Please send us the following parameters to check price for us .The more you order the lower price will be!
Q:What's your discount policy?
A:Admittedly, the best price is determined by your order quantity and detailed requirements.
Q: How can we avoid delay?
A: On-time deliver.
| SPECIFICATIONS | ||||||||||
| RANGE OF OPERATION | Boom length | 5700mm | ||||||||
| Arm length | 2900mm | |||||||||
| Maximum digging radius | 9873mm | |||||||||
| Minimum turning radius | 3560mm | |||||||||
| Maximum digging depth | 6592mm | |||||||||
| Maximum vertical mining depth | 3929mm | |||||||||
| Maximum digging height | 9616mm | |||||||||
| Maximum unloding height | 6830mm | |||||||||
| The radius of the end of gyration platform | 2794mm | |||||||||
| DIMENSION | (Length*width*height) travel position | 9600*2990*3000mm | ||||||||
| Wheel base | 3635mm | |||||||||
| Track Gauge | 2400mm | |||||||||
| Width Of Crawler | 600mm | |||||||||
| Total width of the car | 2990mm | |||||||||
| Total length of walking mechanism | 4440mm | |||||||||
| The total width of belt off | 2980mm | |||||||||
| Ground clearance of counterweight | 1096mm | |||||||||
| Min ground clearance | 475mm | |||||||||
| TECHNICAL PARAMETERS | Angle of rotation | 360° | ||||||||
| Machine weight | 22300kg | |||||||||
| Engine model | Isuzu | |||||||||
| Rated Power | 128.5KW | |||||||||
| Rotary speed | 10.7min | |||||||||
| Walking speed(high/low) | 5.9-3.2km/h | |||||||||
| Ground specific pressure | 43.5kpa | |||||||||
| Climbing ability(%) | 70% | |||||||||
| Digging force | 77.4KN(standard)/81.3KN(turbocharged) | |||||||||
| Volume Of Bucket | 1.2m3 | |||||||||
